True TBB-4G-HC-LD 90" Glass Swing Door Back Bar Cooler
- Design
- True’s refrigerated back bar coolers are designed with enduring quality and value. Our commitment to using the highest quality materials and oversized refrigeration assures colder product temperatures and years of trouble free service.
- Refrigeration System
- Factory engineered, self-contained, capillary tube system using environmentally friendly R290 hydrocarbon refrigerant that has zero (0) ozone depletion potential (ODP), & 0.02 global warming potential (GWP).
- High capacity, factory balanced refrigeration system that maintains cabinet temperatures of 33°F to 38°F (.5°C to 3.3°C) for the best in food preservation.
- State of the art, electronically commutated evaporator and condenser fan motors. ECM motors operate at higher peak efficiencies and move a more consistent volume of air which produces less heat, reduces energy consumption and provides greater motor reliability.
- Condensing unit accessed from behind front grill, slides out for easy cleaning and maintenance.
- Cabinet Construction
- Exterior - Black, powder coated cold-rolled steel with stainless steel countertop.
- Interior - Stainless steel floor with 1/2" (13 mm) reinforced lip and heavy gauge galvanized steel walls.
- Door threshold protector prevents damage to cabinet from routine loading of product.
- Insulation - entire cabinet structure is foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
- Doors
- "Low-E", double pane thermal glass door assemblies with extruded aluminum frames. The latest in energy efficient technology.
- Each door fitted with 12" (305 mm) long handle.
- Positive seal doors.
- Magnetic door gaskets of one piece construction, removable without tools for ease of cleaning.
- Door locks standard.
- Shelving
- Six (6) adjustable, heavy duty, black PVC coated wire shelves. Two (2) right door shelf dimensions are 20–3/4"L x 19–3/8"D (528 mm x 493 mm). Two (2) left and two door shelf dimensions are 31–3/4"L x 21–1/4"D (807 mm x 540 mm). Two (2) center door shelf dimensions are 31"L x 19–3/8"D (788 mm x 493 mm). Four (4) chrome plated shelf clips included per shelf.
- Aluminum shelf support pilasters. Shelves are adjustable on 1/2" (13 mm) increments.
- Lighting
- LED interior lighting provides more even lighting throughout the cabinet. Safety shielded.
- Model Features
- Evaporator is epoxy coated to eliminate the potential of corrosion.
- NSF/ANSI Standard 7 compliant for the storage and/or display of packaged or bottled product.
- Electrical
- Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase - 15 amp dedicated outlet. Cord and plug set included.
- 115/60/1 NEMA-5-15R
- Optional Features/accessories Upcharge And Lead Times May Apply.
- 6" (153 mm) standard legs.
- 6" (153 mm) seismic/flanged legs.
- 2–1/2" (64 mm) diameter castors.
- 4" (102 mm) diameter castors.
- Additional shelves.
- Red wine thermostat
- White wine thermostat
- Chocolate thermostat
True TBB-4G-HC-LD 90″ Glass Swing Door Back Bar Cooler
The True TBB-4G-HC-LD 90″ Glass Swing Door Back Bar Cooler is an ideal refrigeration solution for high-demand commercial environments. With its energy-efficient design, durable construction, and advanced cooling technology, it keeps beverages at the perfect temperature for longer. Perfect for bars, restaurants, and other foodservice settings, this cooler combines functionality with a sleek, modern appearance.
Advanced Refrigeration System
The True TBB-4G-HC-LD features a self-contained, capillary tube system using R290 hydrocarbon refrigerant, which is environmentally friendly with zero ozone depletion potential (ODP) and low global warming potential (GWP). The cooler’s high capacity refrigeration system ensures consistent temperatures between 33°F and 38°F (0.5°C to 3.3°C), ensuring your beverages are always at their best.
-
Electronically commutated fan motors for energy efficiency
-
Factory balanced refrigeration for optimal performance
-
Condensing unit slides out for easy cleaning and maintenance
Durable, Quality Construction
The True TBB-4G-HC-LD cooler is built with black powder-coated cold-rolled steel on the exterior and stainless steel countertop. Its durable construction ensures years of reliable use, while the interior features a stainless steel floor with reinforced lip for easy maintenance.
-
Low-E, double-pane glass doors with extruded aluminum frames
-
Foam-in-place insulation with high-density polyurethane to maintain cold temperatures
-
Magnetic door gaskets are easy to remove and clean
Flexible Storage Capacity
With six adjustable shelves, the True TBB-4G-HC-LD offers versatile storage options for beer kegs, bottles, and cans. The shelves are adjustable on 1/2″ increments, allowing for easy configuration to fit different types of products.
-
Capacity:
-
4 x 1/2-barrel kegs
-
152 six-packs of 12 oz cans
-
-
Shelf Dimensions:
-
Right door: 20–3/4″L x 19–3/8″D (528 mm x 493 mm)
-
Left/center door: 31–3/4″L x 21–1/4″D (807 mm x 540 mm)
-
Efficient LED Lighting
The True TBB-4G-HC-LD is equipped with LED interior lighting, providing energy-efficient illumination while making it easy to see and access items. The lighting is safety shielded for extra durability.
Specifications
-
Model: TBB-4G-HC-LD
-
Door Count: 3
-
Shelf Count: 6
-
Weight: 595 lbs (270 kg)
-
Dimensions:
-
Width: 90–3/8″ (2296 mm)
-
Depth: 27–3/4″ (705 mm)
-
Height: 37″ (940 mm)
-
-
Electrical:
-
Voltage: 115/60/1
-
Amps: 2.8
-
Plug: NEMA 5-15P
-
Optional Features (Additional Charges Apply)
-
6″ standard or seismic/flanged legs
-
2–1/2″ or 4″ castors for easy mobility
-
Additional shelves for extra storage
-
Specialized thermostats for wine or chocolate
